The new Marinetek FA Mooring Fingers have been designed according to the Australian Standards, which are most used in the marina industry. The frame is made of Aluminium and a very strong welded aluminium structure. The Fingers have composite or treated soft wood deck and side fenders and plastic fenders at the top edges. The connection to pontoon is with semi-flexible rubber bolt joints. The Fingers are very stable and long lasting.
A suitable design made and delivered for every situation- Innovative and specialized in anchoring techniques
- Safety and quality are paramount at JLD. We are VCA** and ISO 9001 certified!
- Frame: 6061-T6 grade aluminum to AS 3962-2001 standard
- Float: Rotation molded polyethylene float M31L (260 kg)
- Decking: Treated pine (standard) or wood plastic composite
- Fender: PVC plastic
Fingers of special lengths and widths are also available.
Standard fingers suit best for pontoons with freeboard up to 0.56 m. For higher freeboard, a higher float is available upon request.
Marinetek operates a policy of continous development and reserves the right to change specifications without notice.
| STANDARD MODELS | FA6000 | FA8000 | FA10000 | FA12000 |
|---|---|---|---|---|
| Length (m) | 6,0 | 8,0 | 10,0 | 12,0 |
| Width (m) | 0,7 | 0,7 | 0,7 | 0,7 |
| Total capacity (kg) | 520 | 780 | 1040 | 1300 |
| Joint bolt | 2xM20 | 2xM20 | 2xM20 | 2xM20 |
